The intelligent quantitative automatic filling machine is suitable for quantitative filling of wine, beverages and other liquids. It adopts advanced real-time tracking measurement and control technology to track and detect the liquid level in the electronic valve throughout the process, and is controlled by PLC real-time calculation compensation.

　　The electronic valve and liquid cylinder are designed as a closed liquid flow channel, the flow of liquid from the liquid cylinder to the electronic valve and then to the bottle is smooth and soft, without convective impact of gas and liquid, avoiding the generation of air bubbles. The filling nozzle is designed as a damping orifice, which is blocked in reverse to reduce the impact of liquid flowing into the bottle, thereby reducing the generation of air bubbles.

　　It realizes the filling method of normal pressure liquid feeding and negative pressure defoaming. The liquid filled into the bottle is the difference between the upper liquid level and the lower liquid level set according to the filling capacity requirements, which eliminates the influence of liquid hanging on the wall, eliminates the error caused by liquid level fluctuations, and reduces the impact on filling time. sensitivity.

　　The filling machine has high filling precision, fast speed, no dripping and no choking.

　　The adjustment of all parameters of the intelligent quantitative automatic filling machine can be performed on the touch screen.

　　Bottle height adjustment: To change bottles of different heights, just press the bottle height adjustment button on the touch screen, enter the adjustment amount and press OK, the adjustment mechanism is simple and reliable.

　　Capacity adjustment: The filling machine can adjust the overall capacity and single valve capacity. When filling different capacities, press the capacity adjustment button on the touch screen and input the capacity value.

　　Speed adjustment: adjust by pressing keys on the touch screen (filling speed is related to liquid viscosity, foaming property, temperature, capacity and other factors).

　　Equipment configuration of intelligent quantitative automatic filling machine:

　　The touch screen, PLC, sensor, inverter, etc. are imported from Mitsubishi or technology products imported from the United States, and the cylinders and solenoid valves are made of SMC products.

　　All the parts in contact with the liquid are made of stainless steel 304 or 316, and the key parts are made of 304 stainless steel precision casting, processed by CNC machining center, and the outer surface is smoothed.

　　The seals are made of original imported or imported silicone rubber precision molds, which fully meet the requirements of food hygiene.
