The barrel liquid automatic filling unit is composed of a filling machine and a cap screwing machine/cap capping machine. It can fill liquid materials within the range of 5-30L. Manufacturers can choose different types of filling machines and supporting auxiliary machines according to their own needs. This set of equipment is designed and manufactured with stainless steel material. It is suitable for the metering and filling of fluid and semi-fluid materials without gas in the food, chemical, pharmaceutical and other industries. A series of functions such as capping/capping, coding and so on.

　　Barrel feeding positioning section: The empty barrels in the positioning groove are driven by the roller table, and automatically enter the bottom of the filling head in an orderly and accurate manner. The speed and interval of barrel feeding are fully matched with the filling machine, and the whole group is linked and controlled synchronously. Among them, the round wide-mouth barrel is at the front end of the barrel feeding device, and an automatic barrel feeding device can be added to realize more efficient and fully automatic operation.

　　Weighing filling section: The automatic filling machine adopts weighing filling, which can automatically complete a series of operations such as counting into barrels, metering filling, and conveying out barrels. Different models are equipped with different filling heads, and there are two heads, four heads, six heads, eight heads and so on. The filling head can be adjusted left and right, up and down, using submersible filling, with automatic positioning of the barrel, adjustable speed and capacity, anti-drip, anti-drawing, no filling without a barrel, and high filling accuracy. The liquid cylinders are made of corrosion-resistant stainless steel, which meets the requirements of GMP. PLC intelligent control system, easy to operate, with real-time monitoring, real-time adjustment and fault prompt functions. The electrical system adopts imported components to fully ensure the stability and durability of the equipment.

　　Covering and capping/capping section: Equipped with a fully automatic capping machine to achieve orderly and accurate capping and capping. The small-mouth barrel adopts a fully automatic grab-and-screw capping machine, which can adjust the size and screw capping force according to the size of the barrel cap, and is compatible with a variety of threaded bottle caps; After adjusting the nut position of the corresponding size on the main shaft, the cover can be normally sealed, which is suitable for various international standard barrel covers. The capping/capping mechanism operates stably to ensure the quality and precision of the capping.

　　Can be used for food: purified water, fruit juice drinks, fresh milk, yogurt, sauces, seasoning oil, chili oil, sesame oil, peanut oil, olive oil, linseed oil, rapeseed oil, salad oil, liquor, dew, rice wine, cooking wine, Honey, syrup, etc.

　　Can be used in chemicals: detergent, laundry detergent, alcohol, disinfectant, glass water, antifreeze, industrial oil, paint, liquid fertilizer, etc.

　　It can be used in medicine: traditional Chinese medicine liquid, pesticide liquid, insecticide liquid, herbicide liquid, etc.
