The liquid quantitative filling machine is a high-precision automated filling device developed specifically for the food, pharmaceutical, chemical, and daily chemical industries. It is primarily used for the precise quantitative filling of various liquid materials. Utilizing an advanced metering control system and high-quality valve design, this equipment achieves milliliter-level precision filling according to set parameters, ensuring product consistency and stability.

　　The liquid quantitative filling machine features automatic loading, filling, drip prevention, and counting functions. It is easy to operate and offers flexible adjustments. It is suitable for aqueous solutions, beverages, disinfectants, reagents, and other liquid materials with moderate viscosities. Constructed of high-quality stainless steel, it complies with GMP and food hygiene standards, is corrosion-resistant, and easy to clean, meeting the high-standard production environment requirements of various industries.

　　As a professional manufacturer of automated equipment, Guanshentai's liquid quantitative filling machines offer not only stable operation and high efficiency, but also support customized designs. We can tailor solutions to meet the needs of our customers' production lines, helping them achieve efficient, precise, and intelligent liquid packaging production.

　　Product Description:

　　Piston type automatic filling machine is a new generation of automatic filling machine developed by GuanShenTai with many years of research and development experience and absorbing the world's advanced technology. It adopts piston type metering principle, electronic control and pneumatic components of well-known brands, controlled by PLC with man-machine interface, advanced design, beautiful appearance, friendly interface, adaptability, simple operation, accurate filling volume, easy maintenance and other characteristics. Widely used in a variety of liquids, viscous body, paste filling, replacement of the filling valve (can also be made into a multi-head thick sauce automatic filling machine), but also can be filled with particles containing semi-fluid, paste, sauces and so on.

　　Product features:

　　1)Adopting famous brand components, stable, reliable and durable;.

　　2)Adopting stainless steel frame, easy to clean and meet the standard requirements;.

　　3)Simple adjustment of filling volume and efficiency, touch screen operation and display;.

　　4)No bottle not filling function, liquid level automatic control of filling.

　　5)Filling head has special anti-leakage device, no pulling and dripping phenomenon.

　　6)Different number of filling heads can be designed according to user requirements.

　　Technical parameters:

　　1)Filling capacity: 25-250ml,50-500ml,150-1000ml,500-2500ml(different specifications can be ordered).

　　2) Canning efficiency: 25-40 bottles/minute (6 heads in the range of 50-500ml).

　　3)Canning precision: <±1%.

　　4)Power supply: 220V 50HZ.

　　5)Air pressure: 4-6MPa.

　　6)Overall dimension: 2500*900*2000mm.

　　7)Quality: 650KG.
